Model

Unit

HOMEA-12K

HOMEA-18K

HOMEA-24K

Climate Type

Tropical

T3/T1

T3/T1

T3/T1

Application area

m2

12-20

20-30

30-42

Power Supply

AC Power

Ph-V-Hz

1Ph 208V-240V/50-60HZ

1Ph 208V-240V/50-60HZ

1Ph 208V-240V/50-60HZ

DC Power (PV inSeries)

V

80-380V

80-380V

80-380V

DC Power Current

A

Adviced Solar Panel

Pcs

(3-4)*330W in series

(3-6)*330W in series

(3-8)*330W in series

Rated Cooling

Capacity(T1)

W

3510(900-3900)

5070(1200-6000)

6450(1800-7900)

BUT

12000(3000-13300)

17300(4100-20400)

22000(6100-27000)

Power input(T1)

W

940(190-1270)

1400(220-2100)

1790(300-3200)

Capacity(T3)

W

2910

4290

5130

BUT

9900

14700

17500

Power input(T3)

W

1050

1630

1940

Rated Heating

Capacity

W

4100(1000-4500)

6100(1200-6800)

7800(1800-9100)

BUT

14000(3000-15300)

20800(4100-23000)

26600(6100-31000)

Power input

W

1170(190-1700)

1770(220-2500)

2290(300-3500)

T1 EER (W/W)/ (BTU/W)

/

3.75/12.75

3.60/12.35

3.60/12.30

T3 EER (W/W)/ (BTU/W

/

2.75/9.45

2.65/9.00

2.65/9.00

COP (W/W)/ (BTU/W) )

/

3.50/11.95

3.45/11.75

3.40/11.60

Dehumidification capacity

L/h

1.3

1.7

2.5

Compressor

Model

/

WHP04200

WHP05600

5RD198

Type

/

2xRotary Inverte

2xRotary Inverte

2xRotary Inverter

Brand

/

Highly

Highly

Panasonic

Indoor fan motor

Model

/

BLDC-15W

BLDC-45W

BLDC-45W

Speed(Turbo/Hi/Mi/Lo)

r/min

1300/1200/1100/950

1050/950/850/750

1350/1250/1150/1000

Indoor air flow(Turbo/Hi/Mi/Lo)

m3/h

540/485/435/350

980/880/740/620

1290/1180/1070/900

Indoor noise level (Turbo)

dB(A)

≤42.5

≤46

≤50

Indoor unit

Dimension(W×H×D)

mm

840×205×295

1080×330×237

1080×330×237

Packing (W×H×D)

mm

920×290×360

1140×300×382

1140×300×382

Net weight/Gross weight

Kg

9.0/12.5

15.0/18.5

15.0/18.5

Outdoor fan motor

Model

/

BLDC-40W

BLDC-55W

BLDC-75W

Speed

r/min

880

880

850

Outdoor air flow

m3/h

2100

2200

3300

Outdoor noise level

dB(A)

≤52

≤55

≤58

Outdoor unit

Dimension(W×H×D)

mm

802×564×323

802×564×323

900×700×337

Packing (W×H×D)

mm

910×622×405

910×622×405

1006×755×418

Net/Gross weight

Kg

33.5/37.5

37/42

50/54.5

Refrigerant type

/

R32

R32

R32

Max Design pressure

MPa

4.3/1.5

4.3/1.5

4.3/1.5

Refrigerant copper pipe

Gas side/Liquid side(inch)

inch

3/8 1/4

1/2 1/4

1/2 1/4

Max. refrigerant pipe length

m

15

20

25

Max. difference in level

m

8

10

10

Drain pipe size

mm

16

16

16

Refrigerant connction copper pipe

m

3

4

4

Connection wire length

m

4

5

5

Electronic Expansion Valve

/

Yes

Yes

Yes

Loading QTY 40" Hq/ 20"GP

Sets

200/85

160/75

115/50
