Name: C&I Hybrid All-In-One ESS Cabinet
Brand: https://boost-ess.com/
SKU: 00141
Availability: InStock
Rating: 5 (1 reviews)

Description

System Parameters

Global Leader In Air Domes

Lorem ipsum dolor sit amet, consecte

Our company was founded in Tianhe District, Guangzhou on May 8, 2003

And these two England captains, in fact, were inextricably linked almost 10 years ago. They once attended the same school in London, England. The girl in this photo is now Harry Kane's wife.Beckham has witnessed Kane's growth in the past few years. He once said that Kane had earned the chance for the national team with his outstanding performances.

Our company was founded in Tianhe District, Guangzhou on May 8, 2003

tur adipisc ing elit, sed do Eiusmod Tempor inci didunt ut labore et dolore magna.
Sed ut perspiciatis unde omnis iste natus error sit voluptatem accusantium doloremque laudantium, totam rem aperiam, eaque ipsa quae ab illo inventore.
Ut enim ad minima veniam, quis nostrum exercitationem ullam corporis suscipit laboriosam, nisi ut aliquid ex ea commodi consequatur

Production Experience

650000

Project Areas in 2018

200

Project Patent Technology

10000

Factory Area

System Model	Energy Cuvee 100
DC Parameters
Battery Type	LFP
Combination Mode	1P112S
Rated capacity	280Ah
Rated energy	100 kWh
Rated voltage	358.4V
Rated power	50 kW
Operating voltage range	280V~408.8V
Charge/discharge current	100A / 100A
Cooling Mode	Air Cooling
Cycle Number	6000
Fire Protection System	Aerosol extinguishing
Detector Type	Temperature / Smoke / Water Leak
PV Parameters
Maximum input power	75 kW
Maximum DC input voltage	1000V
Mppt operating voltage range	200-850V
Maximum input current	30A×4
Rated output power	50 kW
Maximum conversion efficiency	98.8%
AC Parameters
Rated output power	50 kW
Rated voltage	3L/N/PE; 220/380V;230/400V;240/415V
Mains Frequency	50/60 Hz
Maximum output current	83A
Power Factor	0.8 Lead... 0.8 Trailing
System Parameters
Operating Environment	-20℃～50℃（Power derating 45℃+）.
Size (WDH mm)	113010001600
Total weight	About 1.4t
Protection class	IP 54
Allowable relative humidity	0-95%
Allowable altitude	≤2000m（power derating 2000m + ）.
Certification Standard	IEC62619、EN62477-1、IEC 63056
